1018039-B Page 8
INSTALLATION
Step 5
Allow at
least 10”
from the
housing
to the
wall.
SIDE WALL
Step 4
Remove the heater housing and
lay it on the ground. Also, temporarily
remove and set aside the service
access door.
The Pilot Pro may be installed near the base
of either side of the heater housing. Choose
which side to mount the Pilot Pro.
Be sure to leave enough room to remove the
pilot pro cover for maintenance access.
Foreasyremovalofthecover,
allowatleast10"ofspacefrom
the heater housing.
To Next Page
