PARTS
24/7 Technical Support- Toll Free 1-877-472-8200
24
Part Number Description
APMF0254 Belt
APMF0255 Pulley
APMF0321 Sleeve
APMF1458 1/2” x 5/16” Keystock
APMF0271 Motor Plate
APMF118 4 Ring Gear - Federal Gear
APMF1183 Ring Gear
APMF1108 1/2” id x 3/4”od Sanoprene Tube
APMF1153 1/2 x 1 x 1/8 Morton Finish Washers
APMF1166 85 mm Snap Ring
APMF1404 Head Mounting Ear
APMF1174 Motor Collar
GPPT0392 Flex Head Assembly
APMF1192 Cross Complete
APMF0272 Frame Assembly
APMF0002 1” Snap Ring
APMF1287 Frame
APMF0007 3/8-16 Nylon Lock Nut , ZP
APMF0094 5/16-18 x 1 1’2 FSHCS, ZP
APMF0119 1/4 x 3/4 Roll Pin, ZP
APMF0131 1/2 x 1 Neoprene Flat Washer
APMF0174 3/8 SAE Flat Washer, ZP
APMF0205 1/4-20 x 2 HHCS, ZP
APMF1289 Inner Weight
APMF1291 Outer Weight
APMF0248 Side Plate
APMF1416 Side Plate Side Pin
APMF1459 G-250XTP Inclined Tube
APMF0249 Axle
APMF0273 Cross Bar 9a
APMF0274 Cross Bar 9b
Concrete Polishing Solutions- G-250XTP Operator’s Manual
