CRADLEPOINT IBR650 | USER MANUAL Firmware ver. 3.3.0
© 2011 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 7
Ethernet Ports: By default, the IBR650 has one WAN (Wide Area Network—your internet source) port and one LAN
(Local Area Network) port. Each of these ports can be reconfigured, however, if you need two LAN or two WAN Ethernet
ports.
Ethernet LED:
 Solid Green – connected
 Blinking Green – data transfer activity
Micro USB: This port can be used to attach a direct firmware upgrade to enable manual firmware upgrades if necessary.
