CRADLEPOINT MBR1200B| USER MANUAL Firmware ver. 3.6.0
© 2012 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 8
LAN and WAN Ports: By default, the four yellow ports are configured as LAN (Local Area Network) ports and the blue
port is configured as a WAN (Wide Area Network—your Internet source) port. Any LAN port, however, can be
reconfigured as a WAN port and vice versa.
Modem Ports: The MBR1200B has two USB 2.0 ports and one ExpressCard port.
Factory Default Reset: You can return your router to factory default settings by pressing and holding the Reset button.
This button is recessed, so it requires a pointed object such as a paper clip to press. Press and hold for 10 seconds to
initiate reset.
WPS Button: WiFi Protected Setup. When you press the WPS button for five seconds, it allows you to use WPS for WiFi
security. The LED will illuminate blue to indicate WPS status. Devices must support WPS in order to be configured by this
method.
Power On/Off:
1 = On
0 = Off
WiFi Broadcast On/Off: You have the option to turn off the WiFi radio.
1 = On
0 = Off
3G/4G Modem Signal Strength Button: When pressed the bar LEDs indicate signal strength from the USB or
ExpressCard modem. The signal strength is shown for 10 seconds if the modem does not support concurrent data
connection and signal strength measurement. Tapping this button will toggle the Modem Signal Strength display on and
off.
