Ethernet Port Configuration
Ethernet Port Configuration provides controls
for your router‘s Ethernet ports. There are five
total ports: one blue port and four numbered
yellow ports. While default settings will be
sufficient in most circumstances, you have the
ability to control: Mode (WAN or LAN) and
Link Speed. Additional controls for WAN ports
are available in Internet → Ethernet
Settings.
Mode: WAN or LAN. Default setting is WAN
(Wide Area Network) for the blue port and LAN
(Local Area Network) for the four yellow ports.
 Internet (WAN) is used to connect to another network such as a hotel or office wired network. The WAN
connection is used as a possible source of Internet for the MBR1200B.
 Local Network (LAN) is for connecting a computer or similar device directly to the router with an Ethernet cable.
Link Speed: Default setting is Auto. The Auto setting is preferred in most cases.
 Auto
 10Mbps - Half Duplex
 10Mbps - Full Duplex
 100Mbps - Half Duplex
 100Mbps - Full Duplex
 1000Mbps - Full Duplex
