CT200-6” JOINTER
CABINET PARTS LIST
REF# PART# DESCRIPTION
200
GB818
M5X16 CROSS PAN HD SCR.
201
GB96
5MM FLAT WASHER
202 BACK SIDE PANEL
203
MB15-
005 FLANGE SCREW
204 150J-06 BELT GUARD
205 WELDING CABINET
206
GB97
6MM FLAT WASHER
207
GB6170
M6 HEX NUT
208
GB818
M5X16 CROSS PAN HD SCR.
209
GB96
5MM FLAT WASHER
210 910353 DUST CHUTE
211
GB6184
M8 SPECIAL HEX NUT
212
GB97
8MM FLAT WASHER
213 4014
SLEEVE
214 4015
WHEEL
215
GB5783
M8X65 HEX HD SCR
216
MOTOR BRACKET
217
503-
1514
MOTOR BRACKET NUT
218
020-
0734
MOTOR BRACKET SCR
219 3015
MOTOR CARRIAGE SCR
220 3004-3
MOTOR CARRIAGE WASHER
221 1062
MOTOR CARRIAGE NUT
222
ORION-
3010
ADJUSTING SCR
223
3/8-16 HEX NUT
224
V-BELT
225
MOTOR PULLY
226
GB78
M6X10MM HEX SOC SET SCR
227
GB1096
5X30MM KEY
228
MOTOR 1HP
229
GB70
M8X25MM HEX SOC HD SCR
230
GB93
8MM LOCK WASHER
231
GB6170
M6 HEX NUT
232
GB97
6MM FLAT WASHER
233
MB15-
005 M6X12 FLANGE SCREW
234
SWITCH ASSY.
235
GB896
9MM EXT RET RING
236
13X30X3MM FLAT WASHER
237
4013
SHAFT
238
GB5780
M8X50 HEX BOLT
239
GB97
8MM FLAT WASHER
240
GB6184
M8 SPECIAL HEX NUT
241
GB6170
M10 HEX NUT
242
GB97
10MM FLAT WASHER
243
GB5780
M8X100 HEX BOLT
244
GB97
8MM FLAT WASHER
245
4009
SPECIAL BOLT
246
1010
TROLLEY WHEEL
247
4010-1
SLEEVE
248
4008
TROLLEY BRACKET
249
GB97
10MM FLAT WASHER
250
GB6184
M10 SPECIAL HEX NUT
251
GB5780
M10X55 HEX BOLT
252
4011
PEDAL BRACKET
253
4012
PEDAL
REF# PART# DESCRIPTION
