Craftex CT201 - Page 25

CT200-6” JOINTER
TABLE PARTS LIST
1
DJ-001
HANDLE
2
DJ-002
STUD
3
DJ-003
BUSHING
4
DJ-004
SHAFT
5
HEX SOC
SET SCR
GB80
(DIN 914)M6X16MM
6
GB80
(DIN 913)M8X10MM HEX SOC
SET SCR
7
DJ-005
CARRIAGE
8
GB6170
UT (DIN 934)M6 HEX N
9
GB5782
(DIN 933)M6X25MM HEX SOC
HD SCR
10 LABEL
11
GB827
RIVET
12
DJ-008
COLLAR
13
DJ-012
SUPPORT
14
DJ-014
WASHER
15
GB6170
(DIN 934)M12 HEX NUT
16
GB70
(DIN 912)M10X50MM HEX
SOC HD SCR
17
DJ-013
WASHER
18
GB70
(DIN 912)M5X16MM HEX SOC
HD SCR
19
9 DJ-00
GIB
20
DJ-010
ECCENTRIC
21
DJ-011
FLAT WASHER
22
GB6170
(DIN 934)M8 HEX NUT
23
DJ-007
SHAFT
24
GB70
(DIN 912)M8X30MM HEX SOC
HD SCR
25
DJ-016
WASHER
26
DJ-015
POINTER
27
GB97
6MM FLAT WASHER
28
GB65
(DIN 84)M6X16MM CHEESE
SOC HD SCR
29
DJ-018
KNOB
30
DJ-019
INDEX PIN ASSY,INCL:
31
GB879
3X20MM SPRING (DIN 1481)M
PIN
32
DJ-020
SPRING
33
GB5782
(DIN 933)M6X25MM HEX HD
SCR
34
GB6170
UT (DIN 934)M6 HEX N
35 SWIVEL
DJ-017
36
DJ-021
COLLAR
37
GB80
(DIN 916)M8X10MM HEX SOC
SET SCR
38
DJ-022
LOCK
39
GB80
(DIN 91
SET SCR
3)M8X12MM HEX SOC
40
DJ-023
CLAMP
41
DJ-024
CLAMP
42
DJ-025
SCALE
43
GB65
(DIN 84)M6X10MM CHEESE
HD SCR
44
GB97
6MM FLAT WASHER
45
DJ-026
BALL HANDLE
46
DJ-027
STUD
47
DJ-028
FENCE
48
DJ-029
SCALE
49
GB827
RIVIT
50
DJ-030A
TABLE RH,INCL;
51
DJ-044A
TABLE SHAFT
52
DJ-032A
XT RABBETING TABLE E
53
M HEX SOC
GB70
(DIN 912)M6X20M
HD SCR
54
DJ-033A
CHIP DEFLECTOR
55
GB70
(DIN 912)M5X12MM HEX SOC
