10
Attach the coolant pump into the coolant
tank and secure it using screws and
washers provided.
Connect the flow tube to the coolant pump
and secure it using a hose clamp provided.
Use a flat head screw driver to tighten the
screw on the hose clamp.
Figure-11 Coolant pump
Place the coolant pump with the coolant
tank inside the stand onto the coolant tank
bracket. The coolant tank has a divider
which holds the tank.
Attach one end of the drain hose onto the
hose connector, underside of the machine
base and the other end into the coolant
tank. See figure-12.
Figure-12 Coolant tank inside the stand
Install the rear stand cover and secure it
using washers and screws provided.
Attach the splash guard to the front side of
the machine and secure it using screws and
washers provided. See figure-13.
Figure-13 Installing the splash guard
WARNING!
Make sure the power cord is
disconnected from the power source
before making any adjustments to the
machine.
