TEST RUN
Once the machine is completely
assembled, test run your machine to make
sure it runs properly.
To test run the machine:
Make sure you have read and understood
the instructions given in this user manual
and the machine is set up properly.
Make sure that there is oil in the machine.
See page-16 for details.
Make sure all the tools and objects used
during assembly are removed from the
machine.
Connect the cord to the power source and
turn the machine ON.
The machine should run smoothly with little
or no vibration.
If there is unusual noise or excessive
vibration on the machine, shut off the
machine immediately. Investigate and
correct it before operating the machine. See
page-17 for TROUBLESHOOTING.
Turn OFF the machine.
BASIC CONTROLS
The basic controls of the CX110 are
described below. Use the following figures
and description to get familiar with your
saw.
ON/OFF SWITCH
Turns the machine power to the machine
ON/OFF.
POWER INDICATOR LIGHT
Glows green when machine is turned ON.
COOLANT PUMP SWITCH
Turns the coolant pump ON/OFF.
EMERGENCY STOP BUTTON
Shuts off the machine incase of emergency.
Figure-14 CX110 Control panel
TRIGGER SWITCH
Turns the motor ON, spinning the blade and
activating the coolant pump.
MITER LOCK LEVER
Releases or locks the head in position for
angled cuts.
WORK-STOP
Allows to set a particular distance from the
blade, producing multiple same length cuts.
VISE HAND WHEEL
Opens and closes the vise jaw to clamp the
work-piece.
