Craftex CX614 - Parts List

18
PART # DESCRIPTION QTY PART # DESCRIPTION QTY
001 Base 1 042 Spring cap 1
002 Hex bolt 4 043 Torsion spring 1
003 Rack 1 044 Spring cover 1
004 Column 1 045 Switch box 1
005 Table bracket 1 046 Screw 4
006 Handle 1 047 Screw 2
007 Setscrew 1 048 Screw 1
008 Shaft 1 049 Clamp cord 1
009 Pin 1 050 Body 1
010 Nut 1 051 Hex bolt 1
011 Washer 1 052 Shifter 1
012 Hex bolt 1 053 Slide bar 1
013 Table bolt 1 054 Slide bar 1
014 Table arm bracket 1 055 Motor base 1
015 Table 1 056 Washer 1
016 Clamp bolt 1 057 Nut 2
017 Gear 1 058 Motor 1
018 Worm gear 1 059 Motor pulley 1
019 Rack ring 1 060 Key 1
020 Pin stop 1 061 Setscrew 1
021 Set screw 1 062 V-belt 1
022 Feed shaft 1 063 Center shaft 1
023 Depth ring 1 064 Ball bearing 1
024 Handle 1 065 Ball bearing 1
025 Bolt 1 066 C-clip 1
026 Handle cap 3 067 Center pulley 1
027 Plate 1 068 Washer 4
028 Bolt 2 069 Screw 4
029 Slide bar bolt 1 070 Screw 1
030 Setscrew 2 071 Washer 1
031 Lock washer 2 072 Knob 1
032 C-clip 1 073 Pulley cover 1
033 Shift bar 1 074 V-belt 1
034 Slide bar bolt 2 075 Pulley nut 1
035 Hex bolt 4 076 Spindle pulley 1
036 Washer 4 077 Insert pulley 1
037 Nut 4 078 C-clip 1
038 Nut 1 079 Ball bearing 1
039 Screw special set 1 080 Spacer 1
040 Nut 1 081 Ball bearing 1
041 Nut 1 082 C-clip 1
CX614 PARTS LIST
