Craftsman 917.270621 - Page 35

ELECTR_r" _ t_
_TRACTOR.:- -..MODEL NUMBER 917,270621
KEY PART
NO. NO.
t 144925
2 74760412
3 STD551025
4 STD551125
6 STD541025
8 156417
16 153664
19 STD551125
20 73350400
21 147430
22 4t52J
24 4799J
25 146147
26 108824X
28 4207J
29 121305X
30 140301
3t 124211X
32 141226
33 109310X
40 156442
4t 71110408
42 131563
43 145673
44 73640400
45 121433X
52 141940
70 140422
DESCRIPTION
Battery 12 VOLT 25 AMP
Bolt Hex Hd 1/4-20unc x 3/4
Vv'asher9/32 x 5/8 x 16 Ga
Washer Lock Hvy Helical 1/4
Nut Fin Hex 1/4-20 Uric
Case Battery
Switch, Interlock Push4n
Washer Lock t/4
Nut Jam Hex 1/4-20 Unc
Harness Asm Light W/4152j
Bulb Light #t156
Cable Battery 6 Ga II" red
Cable Battery 6 Ga w/t6 wire red
Fuse 30 AMP Auto Green
Cable Ground 6 Ga 12" black
Switch Plunger Nc Gray
Switch Ign 4 Pos
Nut Ignition
Cover Sw Key BIk I 25 Text SLT
Key lgn Molded Craftsman
Harness Ign Man C1Am Hm 97
Bolt BIk,,Fin Hex 1/4-20 Unc x 1/2
Cover Terminal Red
Solenoid
Nut Keps Bfk Hex 1/4-20 Unc
Ammeter Rectangular 6 Amp
Protection Wire Loop
Harness Engine B&S 14OHV
NOTE: All component dimensions given in U,S, inches
t inch = 25 4 mm
35
