CHART ‘B’
MODEL
NO
HP VOLT PH Hz
RPM
(Nom)
NEMA
START
CODE
FULL LOAD
AMPS
1.2 SERVICE
FACTOR
AMPS
LOCKED
ROTOR
AMPS
CORD
P/N ▲
CORD
SIZE
CORD
O.D.
WINDING
RESISTANCE
MAIN - - START
4XSCMS Pump
4XSCMS30N4 3.0
208
3 60 1750 K
9.7 11.4
58.2 / 65.8
125496 12/4 - 18/4 .86 ± .02 1.08
230 9.2 10.6 125496 12/4 - 18/4 .86 ± .02 1.08
460 4.6 5.3 32.9 125497 12/4 - 18/4 .86 ± .02 4.32
4XSCMS3054 3.0 575 3 60 1750 N 4.5 4.9 37.0 125497 12/4 - 18/4 .86 ± .02 4.32
4XSCMS50N4 5.0
208
3 60 1750 J
15.8 18.7
82.4 / 92.4
125496 12/4 - 18/4 .86 ± .02 0.72
230 15.0 17.2 125496 12/4 - 18/4 .86 ± .02 0.72
460 7.5 8.6 46.2 125497 12/4 - 18/4 .86 ± .02 2.88
4XSCMS5054 5.0 575 3 60 1750 J 6.0 6.9 37.0 125497 12/4 - 18/4 .86 ± .02 4.32
4XSCMS75N4 7.5
208
3 60 1750 H
23.8 28.5
105.9 / 123.6
125496 12/4 - 18/4 .86 ± .02 0.43
230 23.7 27.2 125496 12/4 - 18/4 .86 ± .02 0.43
460 11.9 13.6 61.8 125497 12/4 - 18/4 .86 ± .02 1.72
4XSCMS7554 7.5 575 3 60 1750 H 9.5 10.9 49.4 125497 12/4 - 18/4 .86 ± .02 2.69
4XSCMC Pump
4XSCMC50N4 5.0
208
3 60 1750 J
15.8 18.7
82.4/92.4
125496 12/4 - 18/4 .86 ± .02 0.72
230 15.0 17.2 125496 12/4 - 18/4 .86 ± .02 0.72
460 7.5 8.6 46.2 125497 12/4 - 18/4 .86 ± .02 2.88
4XSCMC5054 5.0 575 3 60 1750 J 6.0 6.9 37.0 125497 12/4 - 18/4 .86 ± .02 4.32
4XSCMC75N4 7.5
208
3 60 1750 H
23.8 28.5
105.9 / 123.6
125496 12/4 - 18/4 .86 ± .02 0.43
230 23.7 27.2 125496 12/4 - 18/4 .86 ± .02 0.43
460 11.9 13.6 61.8 125497 12/4 - 18/4 .86 ± .02 1.72
4XSCMC7554 7.5 575 3 60 1750 H 9.5 10.9 49.4 125497 12/4 - 18/4 .86 ± .02 2.69
4XSCMC100N4 10.0
208
3 60 1750 E
32.2 41.4
105.9 / 123.6
125498
8/4 - 18/4
1.12 ± .02 0.43
230 29.8 35.6 125498 1.12 ± .02 0.43 460 14.9 17.8 61.8 125497 12/4 - 18/4 .86 ± .02 1.72
4XSCMC10054 10.0 575 3 60 1750 E 11.9 14.2 49.4 125497 12/4 - 18/4 .86 ± .02 2.69
Moisture and Temperature sensor leads are integral to power cord. Winding Resistance ± 7.5% Winding resistance measured in OHMS @ 25°C (Between Lines) at motor leads. Pump rated for operation at ± 10% voltage at motor. ▲ Cord Sufx: XC - 30 Feet, XF - 50 Feet, XJ - 75 Feet, or XL - 100 Feet
▲ Cord sold separately.
Single Phase pumps require start components to be included in panel. Provided with pump.
