19
XSC 18 Frame - PARTS LIST
O-Ring Kit .....................................................138580-XP (+) 5, 9
Seal Kit ...................................... See Table on Page 25
Hardware Kit ................................................138615-XP (♦) 2, 7, 8, 8A
Volute Kit ................................... See Table on Page 20 (■) 10, 11, 41, 42
Impeller Attachment Kit ....................................138614 (○) 8, 8A
Cord Attachment Kit .................................... 140152-18 (π) 2
Lifting Handle Kit ........................................133032-KIT (˃) 2, 23
Leg Kit ....................................... See Table on Page 25
Slicer Blade Attachement Kit .. See Table on Page 24 (○) 7, 8, 8A
Slicer Blade Kit ......................... See Table on Page 23 (∂) 6, 6A, 6B
Shim Kit ..................................... See Table on Page 21 (∆) 50
Striker Plate Kit ......................... See Table on Page 21 (∑) 49, 50, 51, 52
Striker Shell Kit ......................... See Table on Page 21 (⌂) 10, 11, 1, 42, 49, 50, 51, 52
Striker Hardware Kit ................. See Table on Page 21 (∩) 51, 52
Striker O-Ring Stock Kit ........... See Table on Page 21 (▲) 52
ITEM QTY PART NO. DESCRIPTION MATERIAL
1 1 - No Resale Driver Assembly
2 6 127223 ♦ π˃ Screw, SHCS, M12 x 1.75 x 25 18-8 SS
4 1 See Table Seal, Mechanical, Lower
5 2 133048 + Ring, Retaining, EXT, 5100 420 SS
6 See Table ∂ Impeller Ductile Iron
6A 1 See Table ∂ Slicer Blade Stainless 440C
6B 4 See Table ∂ Slicer Pins Stainless 400
7 1 Q21-20-J8 ♦ ○ Key, ¼ x ¼ x 1½” 303 SS
8 1 136284 ♦ ○ Screw,SHCS,M12 x 1.75 x 30 18-8 SS
8A 1 136233 ♦ ○ Washer, Impeller, .50 x 1.50 18-8 SS
9 See Table + O-Ring (Volute) Buna-N
10 See Table ■ ⌂ Wear Ring (Volute) Bronze
11 See Table ■ ⌂ Volute Cast Iron
23 1 133032 ˃ Handle, Lifting 304 Stainless Steel
41 5oz 125502 ■ ⌂ Paint, Epoxy, Part A Epoxy
42 5oz 125503 ■ ⌂ Paint, Epoxy, Part B Epoxy
49 1 See Table ∑⌂ Striker Plate Stainless 440C
50 * See Table ∆∑⌂ Shims Plastic
51 8 143110 ∑⌂∩ Screw, SHCS, M10 x 1.5 x 35 Stainless
8 131147 ∑⌂∩ Screw, SHCS, M10 x 1.5 x 35 (DG Model ONLY)
52 1 See Table ∑⌂∩▲ O-Ring, Buna-N, 70 Duro Buna-N
*NOTE: Quantity dependent on Blade clearance, nominal is 0.09 Shim Stack, with 0.003 gap between Blade and Plate.
