Creality Ender-3 S1 Pro User Manual

11 About the Printer
1
X-Axis Limit Switch
2
Nozzle Module
3
Auto Leveling Module
4
Printing Platform
5
Memory Card Slot
6
Type-C Port
7
Tool Kit
8
Display Screen
9
X-Axis Belt Adjustment Device
10
Filament Detector
11
Rack
12
Z-Axis Motor
13
Y-Axis Limit Switch
14
Voltage Toggle Switch
15
Y-Axis Motor
16
Coupling
18
LED Light
17
X-Axis Motor
Tap “Print". Select the file.
18
17
16
15
14
13
12
9
11
10
1
3
2
8
7
4
5
6

Creality Ender-3 S1 Pro Specifications

General

Build Volume	220 x 220 x 270 mm
Nozzle Diameter	0.4 mm
Max Nozzle Temperature	300°C
Filament Diameter	1.75 mm
Display	4.3-inch color touchscreen
Frame Material	Aluminum
Extruder Type	Direct Drive
Power Supply	350W
Dual Z-axis	Yes
All-metal Hotend	Yes
Supported Filaments	PLA, ABS, PETG, TPU
Connectivity	SD Card, USB
Leveling	Automatic
Printing Speed	150 mm/s
Max Bed Temperature	110°C
