产品简介 Parts List
电源开关
Switch
微动开关
Microswitch
Type-C接口
Type-C interface
保护镜片 Protective lens
护目罩
Protective goggles
护目罩
Protective goggles
TF卡槽
TF card slot
手拧螺丝 Thumb screw
活性炭吸烟棉
Activated carbon
absorbing cotton
电源接口
Packing list
1.6W、5W 激光模组线框图
1.6W、5W laser module wireframes
10W 激光模组线框图
10W laser module wireframe
手拧螺丝 Thumb screw
定焦条 Fixed focus bar

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Creality Laser Module and is the answer not in the manual?

Creality Laser Module Specifications

General IconGeneral
Wavelength450nm
MaterialAluminum Alloy
Input FormatG-Code
CompatibilityCreality 3D Printers
Working Voltage12V
CoolingFan
