CreatBot D600 Pro 2 - Machine Diagram: Printer Head (Part 1); Printer Head Components

Machine Diagram
Front
- 4 -
3
2
4
5
Indicator light
Universal Wheel
U disk input
Power switch
Touch screen
Machine Diagram
New Printer Head
- 5 -
1. PCB box
2. Filament press button
3. Feeding tube
4. Connector
5. Servo
6. Extruder box
7. Cooling fan
1
4
3
6
5
2
7
1
