Creation PCUT SERIES - PCUT S Plotter Parts Identification; Frontal and Back View Components

5.4 Technical features
External size
Transporting
weight
Type CT 630 CT 900 CT 1080 CT 1200 CT 1500
Bracket and paper Table-type M
feeding mode paper foot stool
Vertical feed paper foot stool
Main board 16-bit CPU, 1Mb High-speed CACHE memory
Control panel
Over-head, 2 x 8 Liquid Crystal Display, 13-button touch thin-film keyboard
Drive Main shaft double high torsional motor, micro-step and subdivision driving
Positioning mode Bounded system, arbitrary origin setting,10 Couples origin saving and transfer
Maximum paper
feed width
730mm 1000mm 1100mm 1300mm 1625mm
Maximum cutting
width
640mm 910mm 1010mm 1210mm 1535mm
Maximum cutting
speed
600mm/s
Maximum cutting
length
1500mm (rate <=20 hours) / 15000mm (20 <rate <=60 hours)
/ 5000mm (rate)>=70hours
Maximum cutting
thickness
1mm
Knife press 0-800g (digital adjustment)
Mechanism
precision
0.025mm
<+-0.1mm
Type of tool Sweden SANDWIK hard alloy steel knife
Type of plot pen Atom plot pen and poster pen with a diameter of 11.4mm, watery or oily
Plotting instruction DM-PL/HT-GL(TM) automatic identification
Interface Standard RS232 (serial) / Centronics (parallel)
Power source Ac220 10%. 50Hz
±
Power consumption < 100VA < 120VA
Operating
environment
Temperature: +5 - +35, relative temperature 30% -70%
1030X275 1200X260 1300X260 1500X260 1825X260
X380mm X1070mm X1070mm X1070mm X1070mm
22kg 40kg 42kg 45kg 55kg
