6.4 Technical features
External size 1030X275X380mm 1200X260X1070mm 1300X260X1070mm
Transporting
weight
Type S700 S1000 S1300
Brackcet and paper
feeding mode
Vertical feed paper foot stool
Main board 16-bit CPU, 1Mb High-speed CACHE memory
Control panel
Over-head, 2 x 8 Liquid Crystal Display, 13-button touch thin-film keyboard
Drive Highprecision servo motor driving origin saving and adjustment
Positioning mode Bounded system, arbitrary origin setting, groups of origin and call in
Maximum paper
feed width
730mm 1000mm 1300mm
Maximum cutting
width
640mm 910mm 1210mm
Maximum cutting
speed
700mm/s
Maximum cutting
length
1500mm (rate <=20 hours) / 15000mm (20 <rate <=60 hours)
/ 5000mm (rate)>=70hours
Maximum cutting
thickness
1mm
Knife press 0-800g (digital adjustment)
Mechanism
precision
0.025mm
Repeatable
precision
<+-0.1mm
Type of tool Sweden SANDWIK hard alloy steel knife
Type of plot pen Atom plot pen and poster pen with a diameter of 11.4mm, watery or oily
Plotting instruction DM-PL/HT-GL(TM) automatic identification
Interface Standard RS232 (serial) / Centronics (parallel)
Power source Ac110 10% Ac220 10%. 50Hz
±±
Power consumption < 100VA < 120VA
Operating
environment
Temperature: +5 - +35, relative temperature 30% -70%
22kg 40kg 45kg
Table-type M paper foot stool
Plotting servo machine PCUT S operating instructions PCUT SERIES USER
‘
S MANUAL
