Creative NOMAD Zen XTRA - Page 65

Playing and Managing Your Music 3-26
To use EAX with your currently playing audio:
1. Turn on EAX.
2. Select an EAX setting.
3. Select a preset, rate or mode to use with the selected EAX setting.
This simple process is described in the following instructions.
1. Press the
Menu
button .
2. Scroll Select
EAX Audio
.
3. Follow the corresponding step to either turn on EAX, select an EAX
setting, or select a preset, rate or mode for use with your EAX setting:
To turn on EAX:
Scroll Select
EAX:Off
. The
EAX
icon appears onscreen and is
applied immediately to the audio being played.
To select an EAX setting
Scroll Select
Setting:X
(replace X: with the EAX setting currently
selected). A list appears.
Scroll Select the EAX setting you want.
To select a preset, rate or mode for use with your EAX setting
Scroll Select
Preset:X
,
Rate:X
or
Mode:X
(replace X with the preset,
rate or mode currently selected). A list appears.
