infiNET EX™ Thermostat Crestron CHV-TSTATEX
NOTE: If the system requires a fan, set the top dip switch in the right bank to “on”.
CHV-TSTATEX Sensor Wiring
CHV-RSS
CHV-RTS
RS2 RS 1 RS R RS R
W2 RH
B
O G Y2 Y/Y1
RC
24C
W/W1
16 • infiNET EX™ Thermostat: CHV-TSTATEX Operations & Installation Guide – DOC. 6989A
