LCD Display Elements
# LCD DISPLAY
ELEMENT
DESCRIPTION
1
Large seven-segment
digits
Indicates current ambient temperature
1, 2
. In
Setup mode, indicates current setup
parameter/function.
Display range is limited to –9º to 99ºF (-9º to
43ºC). If the ambient temperature is above
99º, the display will indicate 99º. If the
ambient temperature is below –9º, the
display will indicate –9º.
2
Small seven-segment
digits
Indicates current setpoint (in F or C) in whole
degrees.
While the setpoint is being adjusted, if it is
set to a half-degree increment, the integer
portion of the number will be displayed and
will alternate with “_5” every quarter second
for a period of four seconds after the last
adjustment. After four seconds, only the
integer portion of the number will be
displayed.
In Setup mode, indicates current value for
selected setup parameter.
3 Flame icon
Displayed when the system mode is Heat.
Flashes (on two seconds, off one half
second) when the system mode is Aux Heat
(Emergency Heat).
Displayed with snowflake icon when system
is in Auto mode.
4 Snowflake icon
Displayed when the system mode is Cool.
Displayed with flame icon when system is in
Auto mode.
5 Fan icon Displayed at all times.
6 AUTO indicator
Displayed when FAN setting is AUTO.
If this is not displayed, FAN is always ON.
7 OFF indicator Displayed when the system mode is Off.
8 HOLD indicator Displayed when the HOLD setting is active.
9 H, C, F & A indicators
H – Displayed whenever a Heat Call is being
made.
C – Displayed whenever a Cool Call is being
made.
F – Displayed whenever a Fan Call is being
made.
A – Displayed whenever an Aux Heat Call is
being made.
1. For heat pump and dual-fuel systems, when you select Emergency Heat mode (by pressing and
releasing the MODE button when system mode is Heat) the display will show “EH” in place of the
ambient temperature for two seconds.
2. When the CHV-TSTATEX detects a low battery condition (approximately one month of battery life
remaining), the display will alternate “Lo” in place of the ambient temperature once per second.
Operations & Installation Guide – DOC. 6989A infiNET EX™ Thermostat: CHV-TSTATEX • 27
