Crestron DigitalMedia DM-MD8X8-CPU3 - DMC Output Cards; DMC-4 KZ-HDO Output Card

Product Manual – DOC. 8418A DigitalMedia Switchers
•
71
DMC Output Cards
DMC output cards include the following:
• DMC-4KZ-HDO (see below)
• DMC-4KZ-CO-HD (refer to page 72)
• DMC-HDO (refer to page 73)
• DMC-S2O-HD (refer to page 73)
• DMC-SO-HD (refer to page 74)
• DMC-STRO (refer to page 74)
DMC-4KZ-HDO Output Card
The DMC-4KZ-HDO is a 2-channel HDMI output card that supports 4K60 4:4:4 and HDR
video signals and provides built-in scaling. Two balanced/unbalanced analog audio
outputs are also provided.
DMC-4KZ-HDO Output Card
 HDMI OUT: HDMI Type A connector, female;
HDMI digital video/audio outputs (DVI compatible)
 L, R: 5-pin 3.5 mm detachable terminal blocks;
Balanced/unbalanced stereo line level audio outputs
For additional information, refer to the DMC-4KZ-HDO product page on the Crestron
website.
