Crestron DM-RMC-100 DigitalMedia™ Room Controller, CAT
IP Configuration
If the DM-RMC-100 is used in a standalone configuration (i.e. without a
DM switcher), use Crestron Toolbox to create the IP table entry for the
DM-RMC-100.
NOTE: If the DM-RMC-100 is connected directly to a DM switcher, the
IP table entry for the DM-RMC-100 is created automatically.
1. Use the Device Discovery Tool in Crestron Toolbox to find the IP
address of the DM-RMC-100. Then, display the “System Info”
window (click the
icon) and select the DM-RMC-100 entry
from the Address Book.
2. Select Functions | IP Table Setup.
3. Add, modify or delete entries in the IP table. The DM-RMC-100
can have only one IP table entry.
4. A defined IP table can be saved to a file or sent to the device.
Operations & Installation Guide – DOC. 6743-1F Room Controller, CAT: DM-RMC-100 • 31

Crestron DigitalMedia Room Controller DM-RMC-100 Specifications

General

Category	Controller
Type	DigitalMedia Room Controller
HDMI Output	1 HDMI output
Ethernet	10/100 Mbps; auto-switching
Control System	Crestron
Operating Temperature	32° to 104° F (0° to 40° C)
Humidity	10% to 90% RH (non-condensing)
IR/Serial	Yes
Relay	Yes
USB	Yes
DM 8G+ Input	1 DM 8G+ input
Analog Audio Output	1 analog stereo output
IR/Serial Port	1 IR/Serial port
Relay Port	1 relay port
USB Port	1 USB port
Input Connectors	DM 8G+
Output Connectors	HDMI, Analog Audio, IR/Serial, Relay
Audio Support	Stereo
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
