DigitalMedia™ Room Controller, CAT Crestron DM-RMC-100
Setup
Network Wiring
When wiring the DMNet network, consider the following:
NOTE: DMNet wiring and Cresnet
®
wiring are not compatible.
• Use Crestron Certified Wire.
• Use Crestron power supplies for Crestron equipment.
• Provide sufficient power to the system.
CAUTION: Insufficient power can lead to unpredictable results
or damage to the equipment. Please use the Crestron Power
Calculator to help calculate how much power is needed for the
system (www.crestron.com/calculators
).
• For DigitalMedia CAT wiring, use DM-CBL DigitalMedia Cable.
Up to two DM Repeaters (model DM-DR, sold separately) may be
required. Refer to the latest revision of the Crestron DigitalMedia
Design Guide (Doc. 4789) for complete wiring guidelines.
For more details, refer to “Check Network Wiring” which starts on page
34.
The DM-RMC-100 can also use high-speed Ethernet for communications
between the device and a control system, computer, media server and
other IP-based devices.
For information on connecting Ethernet devices in a Crestron system,
refer to the latest version of the Crestron e-Control

Reference Guide
(Doc. 6052), which is available from the Crestron Web site
(www.crestron.com/manuals
).
18 • Room Controller, CAT: DM-RMC-100 Operations & Installation Guide – DOC. 6743-1F

Crestron DigitalMedia Room Controller DM-RMC-100 Specifications

General

Category	Controller
Type	DigitalMedia Room Controller
HDMI Output	1 HDMI output
Ethernet	10/100 Mbps; auto-switching
Control System	Crestron
Operating Temperature	32° to 104° F (0° to 40° C)
Humidity	10% to 90% RH (non-condensing)
IR/Serial	Yes
Relay	Yes
USB	Yes
DM 8G+ Input	1 DM 8G+ input
Analog Audio Output	1 analog stereo output
IR/Serial Port	1 IR/Serial port
Relay Port	1 relay port
USB Port	1 USB port
Input Connectors	DM 8G+
Output Connectors	HDMI, Analog Audio, IR/Serial, Relay
Audio Support	Stereo
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
