Crestron DigitalMedia Room Controller DM-RMC-100 User Manual

Crestron DM-RMC-100 DigitalMedia™ Room Controller, CAT
DigitalMedia™ Room Controller &
DM
®
CAT Receiver: DM-RMC-100
Introduction
The DM-RMC-100 provides a convenient one-box interface solution to
support a single display device as part of a complete DigitalMedia™
system. It functions as a DM
®
CAT receiver and control interface,
providing a single HDMI
®
output along with a variety of control ports. Its
compact, low-profile design allows the DM-RMC-100 to be installed
discreetly behind a flat panel display or above a ceiling mounted
projector.
Features and Functions
• DigitalMedia receiver and display controller
• DM CAT input supports up to 450 foot (137 meter) cable length
1
• Low-profile surface mount design
• Provides one HDMI
®
or DVI display output
2
• Handles HD video with Deep Color and 3D
• Includes USB HID keyboard/mouse port
• Enables device control via CEC, RS-232, IR, or Ethernet
(Continued on following page)
1. For DigitalMedia CAT wiring, use DM-CBL DigitalMedia Cable. Up to two DM
Repeaters (model DM-DR, sold separately) may be required. Refer to the latest
version of the Creston DigitalMedia Design Guide (Doc. 4789) for complete
wiring guidelines. It is available from the Crestron Web site at
(www.crestron.com/dmresources
).
2. HDMI requires an appropriate adapter or interface cable to accommodate a DVI
signal. CBL-HD-DVI interface cable available separately.
Operations & Installation Guide – DOC. 6743-1F Room Controller, CAT: DM-RMC-100 • 1

Crestron DigitalMedia Room Controller DM-RMC-100 Specifications

General

Category	Controller
Type	DigitalMedia Room Controller
HDMI Output	1 HDMI output
Ethernet	10/100 Mbps; auto-switching
Control System	Crestron
Operating Temperature	32° to 104° F (0° to 40° C)
Humidity	10% to 90% RH (non-condensing)
IR/Serial	Yes
Relay	Yes
USB	Yes
DM 8G+ Input	1 DM 8G+ input
Analog Audio Output	1 analog stereo output
IR/Serial Port	1 IR/Serial port
Relay Port	1 relay port
USB Port	1 USB port
Input Connectors	DM 8G+
Output Connectors	HDMI, Analog Audio, IR/Serial, Relay
Audio Support	Stereo
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
