Crestron DM-RMC-100 DigitalMedia™ Room Controller, CAT
Identity Code
NOTE: In the SIMPL™ Windows program, when the DM-RMC-100 is
dropped onto an output card of a DM switcher, its IP ID is assigned
automatically and does not require additional programming. Use the
information below when the DM-RMC-100 is dropped directly into an
Ethernet slot on the control system in SIMPL Windows, without a DM
switcher.
The IP ID is set within the DM-RMC-100’s table using Crestron
Toolbox™. For information on setting an IP table, refer to the Crestron
Toolbox help file. The IP IDs of multiple DM-RMC-100 devices in the
same system must be unique.
When setting the IP ID, consider the following:
• The IP ID of each unit must match an IP ID specified in the
SIMPL Windows program.
• Each device using IP to communicate with a control system must
have a unique IP ID.
Installation
To prevent overheating, do not operate this product in an area that
exceeds the environmental temperature range listed in the table of
specifications.
The following tools and accessories are required for installation of a
DM-RMC-100:
• DigitalMedia cable (sold separately) terminated with shielded
RJ-45 connectors (DM-CONN, not supplied) for media signals and
mini-phoenix connector for DMNet signals. Refer to “Network
Wiring” on page 18.
• Phillips screwdriver (not supplied)
• Four #06-32 x 1/4" pan head Phillips screws (included)
• Metal mounting plate (included)
• 2-, 4- and 5-pin connector plugs (included)
Operations & Installation Guide – DOC. 6743-1F Room Controller, CAT: DM-RMC-100 • 19
