Crestron DM-RMC-100 DigitalMedia™ Room Controller, CAT
1. Interface connectors for 24 A B G, COM, IR, RELAY and SENS ports are
provided with the unit.
2. HDMI requires an appropriate adapter or interface cable to accommodate a DVI
signal. CBL-HD-DVI interface cable sold separately.
3. Maximum string length for IR commands should be no greater than 40 characters.
4. To determine which is pin 1 on the cable, hold the cable so that the end of the
eight pin modular plug is facing away from you, with the clip down and copper
side up. Pin 1 is on the far left.
5. The DM INPUT port consists of two separate RJ-45 connectors, labeled D and
M. The D port carries HDMI signal. The M port carries data. Refer to the
following table for the connector pinouts.
18
PIN # WIRE COLOR PIN # WIRE COLOR
1 Orange/White 5 Blue/White
2 Orange 6 Green
3 Green/White 7 Brown/White
4 Blue 8 Brown
6. For DigitalMedia CAT wiring, use DM-CBL DigitalMedia Cable. Up to two DM
Repeaters (model DM-DR, sold separately) may be required. Refer to the latest
version of the Creston DigitalMedia Design Guide (Doc. 4789) for complete
wiring guidelines.
7. Refer to the following table for the 24 A B G port connector pinouts.
24
A
B
G
PIN # SIGNAL DESCRIPTION WIRE COLOR
24 24V DC DC Power Red
A DMNet+ DMNet Orange
B DMNet- DMNet Gray
G Ground DC Ground Black
8. DMNet wiring is not compatible with Cresnet
®
wiring. DMNet wiring cannot be
daisy chained.
Operations & Installation Guide – DOC. 6743-1F Room Controller, CAT: DM-RMC-100 17

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Crestron DigitalMedia Room Controller DM-RMC-100 and is the answer not in the manual?

Crestron DigitalMedia Room Controller DM-RMC-100 Specifications

General IconGeneral
CategoryController
TypeDigitalMedia Room Controller
HDMI Output1 HDMI output
Ethernet10/100 Mbps; auto-switching
Control SystemCrestron
Operating Temperature32° to 104° F (0° to 40° C)
Humidity10% to 90% RH (non-condensing)
IR/SerialYes
RelayYes
USBYes
DM 8G+ Input1 DM 8G+ input
Analog Audio Output1 analog stereo output
IR/Serial Port1 IR/Serial port
Relay Port1 relay port
USB Port1 USB port
Input ConnectorsDM 8G+
Output ConnectorsHDMI, Analog Audio, IR/Serial, Relay
Audio SupportStereo
Storage Temperature-4°F to 140°F (-20°C to 60°C)
