Crestron DM NVX Series Design Guide

6 • DM NVX System Design Guide – DOC. 7977F
DM NVX Endpoints (Continued)
FEATURE DM-NVX-350 DM-NVX-350C DM-NVX-351 DM-NVX-351C DM-NVX-352 DM-NVX-352C DM-NVX-E30 DM-NVX-E30C DM-NVX-D30 DM-NVX-D30C
Audio
Inputs 2 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
2 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
2 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
2 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
2 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
Dante and
AES67
2 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
Dante and
AES67
1 x HDMI 1 x HDMI 1 x DM NVX 1 x DM NVX
Outputs 1 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
1 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
1 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
1 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
1 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
Dante and
AES67
1 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
Dante and
AES67
5-pin Phoenix 5-pin Phoenix 1 x HDMI,
5-pin Phoenix
1 x HDMI,
5-pin Phoenix
Digital Input/
Output Audio
Formats
Dolby Digital®,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby® TrueHD,
Dolby Atmos®,
DTS®, DTS ES,
DTS 96/24,
DTS HD® High
Res, DTS HD
Master Audio™,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
DSP Audio
Downmix
— — Yes Yes — — — — — —
Analog Output
Audio Formats
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Analog Input
Audio Formats
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
— — — —
Secondary Audio
Stream Formats
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
— — — —
Dante and AES67
Audio Formats
5
— — — —
Stereo
2-channel
48 kHz
Stereo
2-channel
48 kHz
— — — —
Breakaway Audio
6
Yes Yes Yes Yes Yes Yes — — — —
Available DM NVX Streams
Primary AV
Stream
Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Secondary Audio
Stream
Yes Yes Yes Yes Yes Yes — — — —
Dante Audio
Stream Transmit/
Receive
— — — — Yes Yes — — — —
AES67 Secondary
Audio Stream
Transmit/Receive
— — — — Yes Yes — — — —
(Continued on following page)

Crestron DM NVX Series Specifications

General

Latency	<1 Frame
Dimensions	Varies by model
Weight	Varies by model
Video Input	HDMI
Video Output	HDMI
Audio Formats	PCM, Dolby Digital, DTS
Audio Inputs	HDMI, Analog
Audio Outputs	HDMI, Analog
Control	Crestron Control System
HDCP	HDCP 2.2
Security	AES encryption
