Isys
®
8.4” WiFi Touch Screen Crestron TPMC-8X-GA
TPMC-8X-GA Specifications (Continued)
SPECIFICATION DETAILS
Wireless Communication
(Continued)
Roaming
Requires a Cisco
®
controller solution to be
installed and commissioned by a Cisco
certified technician
Wired Communication
Ethernet
5
10BASE-T/100BASE-TX, auto-switching,
auto-negotiating, auto-discovery, full/half
duplex, TCP/IP, UDP/IP, CIP, DHCP
USB
USB 2.0 host for mouse, keyboard and
USB storage devices
Video
Streaming/File Formats
MJPEG via Crestron MJPEG Viewer, plus
all formats supported by the embedded
media player applications
3
Audio
Hardware Features
Built-in microphone and speakers,
headphone output
Streaming/File Formats
As supported by the embedded media
player applications
3
Audio Feedback
WAV format, 8 & 16 bit PCM, mono &
stereo, 8 – 44.1 kHz sampling rates
Amplification
High efficiency Class D stereo,
2.1 Watts per channel
Battery
Internal Battery
Lithium Ion, 7.4 Volt, 2200 mAh, Crestron
model TPMC-8X-BTP included
Usage per Charge
~1.5 hours continuous, 9+ hours under
normal use with standby/power down
activated
6
Charging Time ~2 hours (~2.5 - 3 hours when in use)
Power Requirements
Power Pack
42 Watts (3.5 Amps @ 12 Volts DC)
100~240 VAC 50/60 Hz power pack
included
Default IP ID
7
03
Minimum 2-Series Control
System Update File
8, 9
Version 3.137 or later
Environmental
Operating Temperature 32º to 104ºF (0º to 40ºC)
Storage Temperature 14º to 140ºF (-10º to 60ºC)
Humidity 10% to 90% RH (non-condensing)
Heat Dissipation 143 BTU/Hr
Enclosure
Plastic front and metal back, stylus storage
slot (stylus included), integral docking
station port
(Continued on following page)
6 • Isys
®
8.4” WiFi Touch Screen: TPMC-8X-GA Operations Guide – DOC. 7078C
