Crestron TPS-6X Series User Manual

Crestron TPS-6X Series Isys™ 5.7” Wireless Touchpanels
Touchpanel Mounting
Magnets
Latch this part of the
docking station onto the
back of the touchpanel first.
Image in circle above,
shows TPS-6XNL-DS,
with no locking mechanism.
Hardware Connections for the TPS-6X-IMCW (Front)
TO PANEL:
Connect to
TPS-6X-DS (or
TPS-6XNL-DS)
via 10-Pin RJ-50
Cable
(Cable Provided
with docking
station)
POWER:
From DC
Power Pack
Operations Guide – DOC. 6875B Isys™ 5.7” Wireless Touchpanels: TPS-6X Series • 37
