Crestron TPS-6X Series Isys™ 5.7” Wireless Touchpanels
Specifications
Specifications for the TPS-6X are listed in the following table.
TPS-6X Specifications
SPECIFICATION DETAILS
Touchscreen Display
Display Type TFT Active matrix color LCD
Size 5.7 inch (14.48 cm) diagonal
Aspect Ratio 4:3 QVGA
Resolution 640 x 480 pixels
Brightness 350 nits
Contrast 400:1
Color Depth 18-bit, 256 k colors
Illumination Backlit fluorescent
Viewing Angle ±80º horizontal, +80º/-70º vertical
Touchscreen Resistive membrane
Processor
CPU 32-bit Freescale ColdFire
®
Microprocessor
Memory
SDRAM 32 MB
Flash 32 MB
Maximum Project Size 28 MB
Graphic Engine
Isys engine; 16-bit non-palette graphics;
65,536 colors; Synapse™ image rendering
algorithm; multi-mode objects; DNav
dynamic menu objects; dynamic graphics;
PNG translucence, full motion (60 fps)
animation; color key video windowing
RF Wireless
RF Transceiver
2-way RF, 2.4 GHz ISM Channels 11-26
(2400 to 2483.5 MHz), IEEE 802.15.4
compliant
Transmitting Power
75 mW (Ch. 11), 100 mW (Ch. 12-23),
15 mW (Ch. 24), 3.5 mW (Ch. 25),
1 mW (Ch. 26) @ High setting;
1 mW (Ch. 11-25), 0.5 mW (Ch. 26)
@ Low setting
Range
100-200 feet (30-61 meters) maximum
indoor, 1000 feet (305 meters) outdoor,
subject to site-specific conditions
Gateway
Requires a CEN-HPRFGW RF Gateway
(sold separately)
Roaming
Supports roaming among up to eight RF
gateways
(Continued on following page)
Operations Guide – DOC. 6875B Isys™ 5.7” Wireless Touchpanels: TPS-6X Series • 5
