Crestron UC-SB1 User Manual

Complete
Once all connections are made, pivot the soundbar up to the wall bracket
until the soundbar locks into place.
Operation
Status
The front panel status bar illuminates to provide operational information.
l A green status bar indicates the volume level. Raising the volume
increases the status bar's illumination. Lowering the volume decreases
the status bar's illumination. When the volume = “0”, the status bar is
unlit.
l Muting the microphone and speaker turns the two outer segments of
the status bar red.
7
UC-SB1
QuickStart
UC Video Conference Smart Soundbar

Crestron UC-SB1 Specifications

General

Product type	Speaker
Certification	CE, IC, UL 62368‑1, CSA C22.2 62368‑1, EN 62368‑1, IEC 62368‑1, FCC Part 15 Class B, ICES‑003 Issue 5 Class B, EN55022:2010 Class B, AS/NZS CISPR22:2010 Class B, AS/NZS CISPR 22:2010 Class B, EN55024:2010, EN61000‑3‑2:2014, EN61000‑3‑3:2013, RoHS compliant
Product color	Black, Grey
Placement supported	Desk
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100‑240V V
AC input frequency	50 - 60 Hz
Heat dissipation	66 BTU/h
USB port	Yes
Bluetooth	No
HDMI ports quantity	-
Connectivity technology	Wired
Woofer diameter (subwoofer)	3 \
Woofer diameter	76 mm
Tweeter diameter	25 mm
Number of tweeter drivers	2
Soundbar speaker RMS power	- W
Woofer diameter (imperial)	2 \
Signal-to-Noise Ratio (SNR)	91 dB
Tweeter diameter (imperial)	1 \
RMS rated power	20 W
Audio output channels	- channels

Weight and Dimensions

Depth	100 mm
Width	1108 mm
Height	118 mm
Weight	6800 g
