Spinna Winna Operators Manual Part No. 990xxx Issue 1
Page 24 of 31
5.10 Accessing the sliding coin entry
To gain access to the coin flipper unit,
open the hinged coin entry door housing
the sliding coin entry.
When closing the hinged coin entry door,
if your machine does not have an
automatic alignment linkage, make sure
that the coin entry chute attached to the
door locates between the side plates of
the moveable flipper unit.
Coin entry door
Automatic alignment linkage
Coin flipper unit
Reject tray
