Spinna Winna Operators Manual Part No. 990xxx Issue 1
Page 6 of 31
3. A STEP BY STEP GUIDE TO SETTING UP YOUR SPINNA WINNA
1 Locate the access door keys attached to
the outside of the machine as shown. The
keys marked “11” open the glass playfield,
the coin entry and the payout doors. The
keys marked “12” open the cashbox doors.
2
Remove the protective cover from the
payout hoppers on all sections if fitted.
UNPACKING
3
The mains power cord and playfield
halogen lamps can be found in the R.H.S.
section (section 1) cashbox.
4
Site the machine on a level surface away
from extremes of temperature or high
humidity.
INSTALLATION
5
Adjust the two stabilizing feet by
turning the shaft using a spanner until the
foot rests on the floor taking the weight
from the front castors.
