Crowcon Xgard - Diagram 6: Xgard Type 4 Dimensioned View

Xgard and Xgard IR Dimensions
11
Diagram 6: Xgard Type 4 dimensioned view
+SIG-
146 mm
166.3 m
Height 111
Hauteur 111 mm
Höhe 111 mm
Altura 111 mm
Hoogte 111 mm
Polish height 111 mm
Altura 111 mm
196 mm
Black
White
+ SIG -
M20, M25,
1/2”, 3/4” NPT
Red
 Internal
grounding
terminal
(earth)
 Additional
external
grounding
terminal
(earth)
 The
detector head
and sensor
retainer
are bonded
together
and must be
replaced as
a unit.
36 mm
M6 / ¼"
