Crown Boiler PHNTM080 - Page 110

108
PREVENT DAMAGE TO THE GAS VALVE.
PLACE A BACKUP WRENCH ON THIS NUT TO
WHEN DISCONNECTING FLEXIBLE GAS LINEFLEXIBLE GAS LINE
CONNECTION
FIGURE 13.0: DISCONNECTING FLEXIBLE GAS LINE
MOUNTING NUT
FLAME ROD
(FOUR PLACES)
BURNER DOOR
IGNITION
ELECTRODE
FIGURE 13.1: FLAME IONIZATION ELECTRODE AND IGNITION ELECTRODE LOCATION
