122
KEY
#
DESCRIPTION
QTY. OR
CROWN
PN
QUANTITY PER BOILER OR CROWN
PART NUMBER
80 100 120 150 180
1 FIXING CLAMP BRACKET 2 EA 430003 430004 430005 430006 430006
2 HOLDING CLAMP 430002 2 EA 2 EA 2 EA 2 EA 2 EA
3 M4 x 6mm FIXING CLAMP SCREW 900240 4 EA 4 EA 4 EA 4 EA 4 EA
4 #10-32 X 1/2” THREAD CUTTING SCREW 900241 8 EA 8 EA 8 EA 8 EA 8 EA
5 BARE HEAT EXCHANGER 1 EA 430013 430014 430015 430016 430016
6 FLUE OUTLET GASKET 430017 1 EA 1 EA 1 EA 1 EA 1 EA
7 FLUE TEMPERATURE SENSOR 430120 1 EA 1 EA 1 EA 1 EA 1 EA
8 REFRACTORY TARGET WALL (WARNING: CONTAINS RCF) 430025 1 EA 1 EA 1 EA 1 EA 1 EA
9 BURNER DOOR GASKET 430020 1 EA 1 EA 1 EA 1 EA 1 EA
10 BURNER DOOR ASSEMBLY (WARNING: CONTAINS RCF) 1 EA 430021 430022 430023 430024 430024
11 FLAME ROD KIT 433030 1 EA 1 EA 1 EA 1 EA 1 EA
11A FLAME ROD 430007 1 EA 1 EA 1 EA 1 EA 1 EA
11B FLAME ROD GASKET 430008 1 EA 1 EA 1 EA 1 EA 1 EA
11C M4 X 10mm ELECTRODE MOUNTING SCREW 900242 4 EA 4 EA 4 EA 4 EA 4 EA
12 IGNITION ELECTRODE KIT 433031 1 EA 1 EA 1 EA 1 EA 1 EA
12A IGNITION ELECTRODE 430010 1 EA 1 EA 1 EA 1 EA 1 EA
12B IGNITION ELECTRODE GASKET 430011 1 EA 1 EA 1 EA 1 EA 1 EA
13 M6 SERRATED FLANGE HEX BURNER DOOR NUT 900243 4 EA 4 EA 4 EA 4 EA 4 EA
14 EDPMO’RING(22mmIDx2mmdia) 430053 2 EA 2 EA 2 EA 2 EA 2 EA
15 CONNECTION CLIP 430054 2 EA 2 EA 2 EA 2 EA 2 EA
16 INTERNAL RETURN PIPING ASSEMBLY 430052 1 EA 1 EA 1 EA 1 EA 1 EA
17 1” NPT CIRCULATOR FLANGE KIT 950151 1 EA 1 EA 1 EA 1 EA 1 EA
18 GASKET, CIRCULATOR FLANGE BULKHEAD 950152 1 EA 1 EA 1 EA 1 EA 1 EA
19 TACO 0013 CIRCULATOR 950161 1 EA 1 EA 1 EA 1 EA 1 EA
19 GRUNDFOS 26-99 CIRCULATOR (ALTERNATE) 95-201 1 EA 1 EA 1 EA 1 EA 1 EA
20 RETURN TEMPERATURE SENSOR 430125 1 EA 1 EA 1 EA 1 EA 1 EA
21 FLOWSWITCHWITHO’RING 430058 1 EA 1 EA 1 EA 1 EA 1 EA
21A NBR O-RING (18mm ID x 2.5mm dia) 430095 1 EA 1 EA 1 EA 1 EA 1 EA
22 SUPPLY TEMPERATURE SENSOR 430122 1 EA 1 EA 1 EA 1 EA 1 EA
23 INTERNAL SUPPLY PIPING ASSEMBLY 1 EA 430055 430055 430056 430056 430056
24 GASKET, SUPPLY PIPING BULKHEAD 430057 1 EA 1 EA 1 EA 1 EA 1 EA
