58
6. Installations using InnoFlue Flex (Vent Options 20,21,37,38):
RefertoCentrothermInnoFlueInstructionsforassemblyofallexcomponentsincludingthechimneycapandtheadaptor
to rigid InnoFlue at the base of the masonry or B vent chimney. In addition, observe the following requirements:
a) RefertotheappropriateVentoptioninTables7.13bor7.21foralistoftheprincipleexcomponentsrequired.Rigid
vent pipe by the same manufacturer will also be required for the run from the boiler to the base of chimney.
b) Masonry chimneys cannot be used for an air chase
c) B vent chimneys can only be used for an air chase (Vent options 20, 21) if the B vent has the minimum size shown in
Table 7.13b and is fully accessible for sealing of all joints and seams.
d) When Vent Options 20, 21 are used, install a Tee of the same size at the base of the vent. Route the smooth section of
InnoFlue Flex (3”) or Flex Adaptor (2”) through a cap in the base of this Tee. Use a Centrotherm IAWP2P or IAWP03B
wall plate and RTV to seal this penetration. Install the Base Support using the Base support bracket as described in the
InnoFlue installation manual.
Connection of the PVC air intake pipe to the side outlet of the tee is made using a cap and a PVC socket x male thread
adaptor (2” or 3”, depending on the Vent Option). Cut a clearance hole in the cap for the male threads. Secure the adaptor
to the cap using a 2” or 3” electrical conduit lock nut. Seal all joints with RTV.
