Crown CTs Series User Manual

page 43
CTs Power Amplifiers
Operation Manual
5.2.4 Channel Level Control
The signal level for each input can be attenu-
ated accurately by adjusting the 21-step Level
Control (see Section 4.2). Figure 5.2 shows the
amount of attenuation in dB for each detent.
Note: Attenuation per detent varies with operat-
ing mode since gain varies with operating
mode. Attenuation amounts shown may vary
±6%.
Detent 4/8 Ohm 70V 100V
0 (full CCW) 68.31 72.90 71.02
1 67.54 72.06 70.26
2 32.23 36.61 34.90
3 25.46 29.74 28.00
4 21.83 25.87 24.22
5 19.23 23.20 21.58
6 17.12 20.94 19.40
7 15.36 19.02 17.53
8 13.76 17.22 15.79
9 12.28 15.53 14.20
10 10.84 13.90 12.62
11 9.51 12.32 11.16
12 8.28 10.87 9.81
13 7.09 9.45 8.45
14 6.30 8.11 7.22
15 4.92 6.70 5.94
16 3.82 5.26 4.63
17 2.62 3.70 3.21
18 1.35 1.90 1.66
19 0.01 0.01 0.01
20 (full CW) 0.00 0.00 0.00
ATTENUATION in dB
Figure 5.2 Level-control Attenuation per Detent in CTs Multichannel Amplifiers
5 Advanced Features
and Options

Crown CTs Series Specifications

General

Power Output	Varies by model (CTs 4200, CTs 3000, CTs 2000, CTs 1200, CTs 600)
Total Harmonic Distortion	< 0.05% (at full rated power)
Input Sensitivity	1.4V for rated power
Weight	Varies by model (e.g., CTs 2000: 25 lbs)
Channels	2
8 Ohm Stereo (per channel)	Varies by model
4 Ohm Stereo (per channel)	Varies by model
2 Ohm Stereo (per channel)	Varies by model
8 Ohm Bridge-Mono	Varies by model
4 Ohm Bridge-Mono	Varies by model
Voltage Gain	32dB
Damping Factor	>500
Cooling	Variable-speed fan
