page 43
Operation Manual
DCi Specications
DCi Model 4/8 Ohm 70Vrms 100Vrms
8|600ND 34 dB 34 dB 34 dB
4|1250ND 34 dB 34 dB 34 dB
Voltage Gain (at maximum level setting)
DCi Model 4/8 Ohm 70Vrms 100Vrms
8|600ND 1.4V 1.4V 2.0V
4|1250ND 2.0V 1.4V 2.0V
Input Sensitivity
DCi Model Channels 2 Ohms 4 Ohms 8 Ohms 16 Ohms 70Vrms 100Vrms
8|600ND 8 300 600 600 300 600 600
4|1250ND 4 1250 1250 1250 625 1250 1250
Dual-Mode - All Channels Driven
Minimum Guaranteed Power (20 Hz - 20 kHz)
DCi Model 4 Ohm 8 Ohms 16 Ohms 140Vrms 200Vrms
8|600ND 600 1200 1200 1200 1200
4|1250ND 2500 2500 2500 2500 2500
Bridge Mono Mode - All Channels Driven
Minimum Guaranteed Power (20 Hz - 20 kHz)
DCi Model Width Height Depth
8|600ND 19 in (48.3 cm) 3.5 in. (8.9 cm) 17 in. (43.2 cm)
4|1250ND 19 in (48.3 cm) 3.5 in. (8.9 cm) 17 in. (43.2 cm)
Dimensions
