Figure 40 Signal Path
Signal Path
FPGA bluLink engine
AVB
NODE
Analog
Input
+6dB Gain
34dB or
28dB
overall
Analog Input 1 Analog Input 2
Analog
To
Digital
Converter
AVB Input
AVB Output
Cross
Point
Signal
Matrix
Ch 1
Priority
Input Router
Input
Delay
2-sec
Input
EQ
1-8
Xover
+
BP-gain
Output
EQ 1-8
Driver
Delay
0.1-sec
Limiters
Auto-
Standby
Σ
Ch 2
Priority
Input Router
Σ
trim
mute
+
polarity
trim
mute
+
polarity
Input
Y
Amp
Load
Monitor
Amp Output
clip
detect
clip
detect
/ 8-ch
Processing Output
Hi/LoZ
70/100V
fader
mute
+
polarity
Back
panel
attn
Input
Delay
2-sec
Input
EQ
1-8
Xover
+
BP-gain
Output
EQ 1-8
Driver
Delay
0.1-sec
Limiters
Amp
Load
Monitor
Amp OutputProcessing Output
fader
mute
+
polarity
Back
panel
attn
Auto-
Standby
trim
mute
+
polarity
clip
detect
trim
mute
+
polarity
clip
detect
Analog Inputs
Amplifier Outputs
High Priority
Input
Med Priority
Input
Low Priority
Input
High Priority
Input
Med Priority
Input
Low Priority
Input
Thermal
comp
RMS
Voltage
Speaker
Thermal
Peak
Voltage
Vcc
Limiter
Clip
comp
Vout
limiter
LevelMAX Limiter
Signal
Generator
Mode()
Freq()
4-eq filters
Input Router
DCi-ND Signal Path
fader
mute
+
polarity
clip
fader
mute
+
polarity
clip
Enable
Master
fader
mute
fader
mute
Crossover Bypass
Crossover Bypass
Pilot
Tone
Detect
Pilot
Tone
Detect
Invert
Bridge
clip
clip
clip
