K-Series Balanced Current Amplifier™
Quick Start!
First things first. We know you just can’t wait to
crank up your new Crown
®
K-Series amplifier.
And the last thing you want to do is dig through
pages of tech-talk to find out where the “ON”
switch is. So that’s why we provided you with this
quick and simple page to get you up and running
right away. Just take a few minutes to read through
this—no more than five or ten, max—you’ll be glad you did.
1. Make sure the
K-Series amp and all other equipment is
turned OFF before you begin wiring. The amp power switch,
which is located on the far right side of the front panel, is
“OFF” when pressed downward.
2. Mount your
K-Series amp securely in the rack.
3. Connect the left and right inputs coming from your mixer,
preamp, or other processor. You can use either balanced
1/4-inch phone or 3-pin XLR connectors. You can also
choose to run in MONO mode, with either bridged outputs,
“Y” inputs, or both. If so, see the sections starting on page 14
for further instructions.
4. Connect the output wiring (left and right speakers).
5. Connect your
K-Series amp and other equipment to the ap-
propriate power source.
6. Turn on your mixer, preamp, signal processor, or any other
equipment in your system EXCEPT your
K-Series amplifier.
(Remember: save the best for last.)
7. Make sure the Channel 1 and Channel 2 level (volume) con-
trols on your
K-Series amplifier are turned all the way down
(counter-clockwise), then flip the power switch “ON” (press
upward). Note: After a two-second delay, the “Enable” light
will glow a bright green to indicate power is on. If no audio
signal is present at the amp, the enable light will then switch to
a dim green.
