Crystal XP2 User Manual

PN: 2975 Rev F, 3/2004
Page 18 of 24
PRESSURE is Our BUSINESS
™
Pressure Ranges, Display Scales & Resolution
PSI Bar kPa
(4)
Part #
Prefix
Range
PSI
(2)
max
PSI
(3)
Part #
Prefix
Range
bar
(2)
max
bar
(3)
Part #
Prefix
Range
kPa
(2)
max
kPa
(3)
PSI kg/cm
2
inch
Hg
inch
H
2
O
mm
Hg
mm
H
2
O kPa
(4)
Bar
(4)
mBar
(4)
15PSI 15 100 1BAR 1 7 100KPA 100 700 0.001 0.0001 0.001 0.01 0.01 1 0.01 0.0001 0.1 30PSI 30 100 2BAR 2 7 200KPA 200 700 0.001 0.0001 0.001 0.01 0.1 1 0.01 0.0001 0.1
100PSI 100 200 7BAR 7 14 700KPA 700 1400 0.01 0.0001 0.01 0.1 0.1 1 0.01 0.0001 0.1 300PSI 300 600 20BAR 20 42 2KKPA 2000 4200 0.01 0.001 0.01 0.1 1 0.1 0.001 1 500PSI 500 1000 30BAR 30 70 3KKPA 3000 7000 0.01 0.001 0.1 1 1 0.1 0.001 1
1KPSI 1000 2000 70BAR 70 140 7KKPA 7000 14000 0.1 0.001 0.1 0.1 0.001 2KPSI 2000 4500 140BAR 140 350 14KKPA 14000 35000 0.1 0.01 0.1 1 0.01 3KPSI 3000 4500 200BAR 200 350 20KKPA 20000 35000 0.1 0.01 0.1 1 0.01 5KPSI 5000 7500 300BAR 300 450 30KKPA 30000 45000 0.1 0.01 1 1 0.01
10KPSI 10000 15000 700BAR 700 1000 70KKPA 70000 100000 1 0.01 1 0.01
(1)
Pressure units not desired may be disabled via RS-232, using optional WinXP2 configuration software.
(2)
XP2s will indicate pressure up to 10% above this number. Above 110% of this rating the XP2 display will flash, indicating that the applied
pressure exceeds the calibrated pressure range, and that the displayed pressure may not be accurate.
(3)
Max PSI, max Bar and max kPa are the maximum pressures the gauge can withstand without damage. The gauge will not indicate
pressure up to this number.
(4)
kPa models can display pressure in kPa and Bar (or mBar), only. PSI and bar models have all available units.

Crystal XP2 Specifications

General

Accuracy	±0.25% FS
Display	LCD
Pressure media	Non-corrosive gases
Operating temperature	32°F to 122°F (0°C to 50°C)
Measurement Range	0 to 15 psi
Operating Humidity	90% RH (non-condensing)
