PN: 2975 Rev F, 3/2004
Page 19 of 24
C R Y S T A L
engineering corporation
Specifications
Accuracy specifications are for one year, and include all effects of linearity, hysteresis,
repeatability, and temperature within the specified operating temperature range.
The gauge must be exercised and re-zeroed whenever exposed to significant changes in
environmental conditions to achieve these specifications. To exercise the gauge, cycle the
gauge between zero and the pressure of interest. A properly exercised gauge will return to a
perfect zero reading.
Exposure to environmental extremes of temperature, shock and/or vibration may warrant a
more frequent recertification period.
Accuracy
20 to 100% of Full Scale: ±0.1% of reading
0 to 20% of Full Scale: ±0.02% of Full Scale
Vacuum*, for 2000 kPa (300 PSI) and lower pressure gauges:
0 to -14.5 PSIG (0 to -99.9 kPa): ±0.25% of Full Scale,
where F.S. = -14.5 PSI (-99.9 kPa)
*Not specified for 500 PSI/ 30 bar/ 3000 kpa models and higher, although all models can
be safely connected to vacuum.
Temperature
Operating & Compensated Range: -10°C to 50°C (14°F to 122°F)
Storage Range: -20°C to +70°C (-4°F to +158°F)
Humidity
Temperature Range Humidity
-10 to 10°C ........................ Uncontrolled
10 to 30°C ......................... 0 to 95% Relative
30 to 40°C ......................... 0 to 75% Relative
40 to 50°C ......................... 0 to 45% Relative
Media Compatibility
Liquids and gases compatible with 316 Stainless Steel.
Pressure Conversions
1 PSI = 27.6806 inches of water column (water at 4°C [39.2°F])
27.7070 inches of water column (water at 15.6°C [60°F])
27.7292 inches of water column (water at 20°C [68°F])
2.03602 inches of mercury (mercury at 0°C [32°F])
6.8948 kilopascals
51.7149 millimeters of mercury (mercury at 0°C [32°F])
703.087 millimeters of water column (water at 4°C [39.2°F])
0.068948 bar
68.948 millibar
0.070307 kilograms per square centimeter
