ASH BOX
Carry out the following at least once per week:
Open the door under the hearth, unscrew the nut and remove the ash box with care.
Empty or clean out all the ash when the stove is cold, taking care that there are no
cinders present. Place the box back in its place an tighten the nut.
In ARMONIA and INSERTO CAMINETTO models the box can not be
removed, therefore after removing the crucible suck out the ash present on the
bottom with a vacuum.
INSIDE THE HEARTH
Carry out the following at least once per week:
Open the door of the combustion room and remove the crucible. Remove the
fixings (fig. 25) and remove the hearth sides from the combustion room: a
central one, two side one and an upper one (when present with the model)
checking the state of the pyroceram fibre ring (fig.26) that, when required, is
to be replaced only by a qualified person. Now remove all the ash present
inside the inspecting bulkheads (fig.27) and behind the door (when present
with the model) placed under the falling pellet tube.
Furthermore, especially check for, and remove, ash from the sides of the tubing (fig.28) placed in the upper part
of the combustion room.
COMBUSTION SMOKE TUBING
The combustion smoke tubing and the entire flue must be checked and cleaned at least once a year. We
recommend the use of a specialized technician for thorough and professional cleaning.
COMBUSTION AIR INTAKE
During weekly cleaning remember to check that the air intake tube (fig.29)
positioned under the start-up resistors is not blocked by any alien material. If
necessary remove it.
Fig. 24
Fig. 26
Fig. 25
Fig. 28
Fig. 29
