CitySlickerOwner’sandServiceManual
www.CSCMotorcycles.com

28

Notethelocationofthebushingbetweentheleftfrontfork
andthewheelhub.

Theleftbushinghasaslotatthetop,whichmustengagethe
tabontheleftforklowercasting.

Notethealignmentoftheleftfrontforklowercastinghub
andthehubslot.Thesetwomustbealignedforreassembly.

Atthispoint,thefrontwheelcanberemovedfromthemotorcycle.
Assemblyisthereverseofdisassembly.Installanewfrontdisk,usingblueLoctite.

RearWheelRemoval

Caution!Makesurethemotorcycleisonastablesupportwhenperformingthisoperation.
Lifttherearwheeloffthegroundwithamotorcyclejackor
othersuitablesupport.Itisnotnecessarytoremoveany
bodypanelsifthemotorcyclejackispositioneddirectly
beneaththemotorasshownhere.

