CitySlickerOwner’sandServiceManual
www.CSCMotorcycles.com

33

Thebrakeusesthesamepartnumberpadsforboththe
innerandouterapplications.

Warning!Testthebrakesafterinstallingthenewpadsand
beforeventuringintotraffic.

Asnotedabove,thebrakepadshaveaweargroovemachinedintothepadsurface.Wheneitherpad
iswornsuchthattheweargrooveisnolongervisible,replacebothpadswithnewpads.CSCstocks
thesepads,socallusat9094450900ifyouneedtoorderapair.
Assemblyisthereverseofdisassembly.Installnewfrontpads,placethecaliperovertherotor,and
installthetwocalipermountingbolts.

FrontRotorInspectionandReplacement

Thefrontbrakediskisawearitem.Itmustberemovedandreplacedwhentherotorthicknessfalls
below3mm.Thediskcanbeinspectedwiththefrontwheelonthemotorcycle.Thefrontwheelmust
beremovedinaccordancewiththeprocedureoutlinedinthismanualtoreplacetherotor.

Afterremovingthefrontwheel,gentlyheattheAllenbolts
securingtherotortothewheelhub.Unscrewtheboltsto
allowrotorremoval.

CSCstocksbrakerotordisks,socallusat9094450900ifyouneedtoordernewdisks.
Assemblyisthereverseofdisassembly.Installanewfrontdisk,usingblueLoctite.

RearBrakePadInspectionandReplacement

Youcanreplacetherearbrakepadswiththemotorcycleonitssidestand.Youdonotneedtoremove
therearwheelorputthemotorcycleonajacktoreplacetherearbrakepads.

Youcanseethebrakepadswiththecaliperonthemotorcyclebypositionyourselfbeneathandtothe
rearofthecaliper.Itiseasiertoseethebrakepadsbyremovingthecaliper.
