ElectricalSystem

TheCitySlickerelectricalsystemconsistsoftheinstrumentation,theturnsignals,theswitches,thelights,the
controller,afuse,acircuitbreaker,thehorn,andassociatedharnessesandcircuitry.

ElectricalComponentsLocation

TheCitySlicker’selectricalcomponentsarelocatedundertheseat(theDCconverter,thefuse,andconnector
plugs and harnesses), in the battery compartment (the battery, the controller, and harnesses and related
connectors),intheheadlight/instrumentcluster(lamps,harnesses,andrelatedconnectors),inthehandlebars
(theswitches),intheturnsignals(LEDassemblies),andontheframeinfrontofthebatterycompartment(the
horn).Accesstotheunderseatcomponentsisprovidedbyusingtheignitionkeyinthelockontheleftbodypanel
andremovingtheseat.Thesecomponentsareshownbelow.

Inserttheignitionkeyintheleftunderseatbodypaneland
turnittounlocktheseat.
Lifttheseatoffthemotorcycle.

Airswitch.

