CitySlickerOwner’sandServiceManual
www.CSCMotorcycles.com

30


Brakes

Maintenanceproceduresforthefrontandrearbrakesareprovidedbelow.

FrontBrakePadInspectionandReplacement

Itispossibletoinspectbrakepadwearwithoutremovingthecaliperorthebrakepadfromthe
motorcycle.Doingsoinvolvesviewingthepadsfromthefrontofthecalibertoinspectgroovedepth,as
showninthephotobelow:

Pushthewheelforwardandtakethebeltofftherearwheel
pulley.

Slidetherearwheeltotherearandremovethebushing
fromtherearwheelpulley.

Slidetherearoutoftheswingarm.

Assemblyisthereverseofdisassembly.Aligntherearwheelinaccordancewiththebeltadjustment
andrearwheelalignmentprocedureshowninthismanual.
