CSC City Slicker - Instrument Cluster Removal and Replacement; Ignition Switch Removal and Replacement

CitySlickerOwner’sandServiceManual
www.CSCMotorcycles.com

53

Assemblyisthereverseofdisassembly.
CSCstocksreplacementlamps.Ifyouneedareplacementlamp,pleasecontactCSCat9094450900.

InstrumentClusterRemovalandReplacement

Theinstrumentclusterisattachedtotheheadlightassemblywithtwothreadedfastenersaccessiblefromthe
undersideoftheheadlightsubassembly.Togainaccess,youwillneedtoremovetheheadlightsubassemblyas
outlinedintheheadlightreplacementsegmentofthismanual.Disconnectthefastenersandtheconnectors.The
instrumentclusterisnotarepairableitem;itmustbereplacedasasubassembly.

CSCstocksreplacementinstrumentclusters.Ifyouneedareplacementinstrumentcluster,pleasecontactCSCat
9094450900.

IgnitionSwitchRemovalandReplacement

Toreplacetheignitionswitchmodule,removetheheadlightandinstrumentclusterasdescribedabovetoget
access.

Theignition switch module is provided witha newignition key.  Note that after replacing the ignition switch
module,youwilleitherneedtoreplacethebatteryandseatreleaselocks,oryouwillneedtokeepthekeysto
operatethoselocks.Thenewkeywillnotfittheseotherlocks.

Disconnecttheignitionswitchconnector.

Removethetwoboltssecuringtheignitionswitchmoduleto
theuppertripletee.

Assemblyisthereverseofdisassembly.
CSCstocksreplacementignitionswitchmodules.Ifyouneedareplacementignitionswitchmodule,
pleasecontactCSCat9094450900.




